Quantity: | |
---|---|
H3500
FOTMA
H3500
9000W*2
Three-phase four-wire, 380V, 50Hz
TECH DATA | ||
Model | H3500 | |
Raw material ratio | 1:1 | |
Raw material viscosity range | 200-1000CPS | |
Raw material output | 2~8 kg/min | |
Heater heating power | 9000W*2 | |
Pipeline insulation heating power | Pipe 3200W | |
Heating temperature range | 0℃~90℃ | |
Power requirements | Three-phase four-wire, 380V, 50Hz | |
Working hydraulic pressure | 8-12Mps | |
Single component raw material output pressure | 26 MPa | |
System pressure | 25Mpa | |
Insulation pipe group support head (optional) | 90 meters | |
Spray gun cleaning method | High pressure mechanical cleaning | |
Drive way | Hydraulic drive | |
Package size | 1100mX 100mX 135m | |
Shipping weight | 250Kg | |
Scope of application | Used in large-scale residential, commercial, and industrial building bead spraying engineering; heavy anti-corrosion engineering, fire protection engineering, waterproof engineering, etc. | |
Standard configuration | Host: 1 Tools: 1 set 1 set of short gun barrel: 3 meters Spray gun: 1 Operation manual: 1 set Feed pump: 2 1 set of heating and heat preservation pipeline: 15 meters Certificate: 1 copy Random accessories: 1 set |
TECH DATA | ||
Model | H3500 | |
Raw material ratio | 1:1 | |
Raw material viscosity range | 200-1000CPS | |
Raw material output | 2~8 kg/min | |
Heater heating power | 9000W*2 | |
Pipeline insulation heating power | Pipe 3200W | |
Heating temperature range | 0℃~90℃ | |
Power requirements | Three-phase four-wire, 380V, 50Hz | |
Working hydraulic pressure | 8-12Mps | |
Single component raw material output pressure | 26 MPa | |
System pressure | 25Mpa | |
Insulation pipe group support head (optional) | 90 meters | |
Spray gun cleaning method | High pressure mechanical cleaning | |
Drive way | Hydraulic drive | |
Package size | 1100mX 100mX 135m | |
Shipping weight | 250Kg | |
Scope of application | Used in large-scale residential, commercial, and industrial building bead spraying engineering; heavy anti-corrosion engineering, fire protection engineering, waterproof engineering, etc. | |
Standard configuration | Host: 1 Tools: 1 set 1 set of short gun barrel: 3 meters Spray gun: 1 Operation manual: 1 set Feed pump: 2 1 set of heating and heat preservation pipeline: 15 meters Certificate: 1 copy Random accessories: 1 set |
