Epoxy/Polyester Powder Coatings

Epoxy/polyester powder coatings has high cost performance, excellent interior decoration, good adhesion, high hardness, impact strength, flexibility and other physical and mechanical properties; in addition to alkali resistance, other chemicals resistance performance and storage performance are good.
Quantity:
  • FOTMA
  • indoor office equipment, etc.
  • Uniform color, no foreign matter, loose powder
  • Carton packaging
Epoxy/Polyester Powder Coatings

Product features
Epoxy/polyester powder coatings has high cost performance, excellent interior decoration, good adhesion, high hardness, impact strength, flexibility and other physical and mechanical properties; in addition to alkali resistance, other chemicals resistance performance and storage performance are good.

Scope of application
Epoxy/polyester powder coatings are widely used in indoor office equipment, office supplies, sports equipment, household appliances, kitchen utensils, furniture, hardware products, instrument housings, auto parts, mechanical parts, supermarket shelves, etc.

Product packaging
Carton packaging, lined with polyethylene plastic bags,and net weight of 20kg.

Membrane performance
Indicator name Skills requirement
Membrane appearance The film is flat and the color meets the specified color difference range
hardness ≥ 2H
Attached Focus / Level≤ 0
Resistance to shock/ kg*cm Positive rush reverse rush 50
Bending test/mm 1
Cupping test/ mm 6
Gloss(60° ) According to customer requirements
Alkali resistance(5%Na0H) 240h NA
Acid resistance(3%HCL) 240h NA
Boiling water resistance 240h NA
Humidity and heat resistance 500h NA
Film thickness 70 um -120 um
Salt spray resistance(800h) Marking point: one-way rust ≤2.0mm; Unlined area: No difference

Powder performance
Indicator name Skills requirement
Color and art effect According to customer requirements
State in the container Uniform color, no foreign matter, loose powder
Density(25℃) 1. 3-1.8g/cm⊃3;
Non-volatile content >99. 4%
Residue on sieve (125um) All passed
Curing time 180- 200°C * 15 -20min
