FM600-Q6 Series Pneumatic Thin Type Ball Valves

Fire-proof, stactic-proof structure, ludox precision casting, safe & reliable.
Quantity:
  • FM600-Q6 Series

  • FOTMA

  • DN15~100mm

  • 1.6Mpa

  • PTFE(F)、PPL ( PPL)

FM600-Q6 Series Pneumatic Thin Type Ball Valves

Basic Description
Nominal Diameter DN15~100mm

  Ultra thin design, light and fast, quick response, zero leakage.

  Fire-proof, stactic-proof structure, ludox precision casting, safe & reliable.

  Apply with ISO5211 standard high platform design, ultra-long durability.

  Bidirectional sealing, bidirectional pressure-bearing, self-compensation, self cleaning function.

  Applicable for with fiber containing particle and high viscous media.


Technical Parameters

Technical Parameter
DN DN15~100mm
Nominal Pressure 1.6Mpa ( lf need other standardplease indicate when ordering )
Body Material Carbon steel(C)Stainless 304(P)Stainless 316(R)
Seal Material PTFE(F)PPL ( PPL)
Media Temperature W2:-20~150℃  W3:-20~250℃
Connection Mode Butt Clamp
Pneumatic Actuatcr FMAT seriesFMAW serieslmport actuator series
Interaction Way Double actionSingle acting normally closedSingle acting normally open

Notes: Other special sealing material or special temperature can choose by customer's design.

Installation Size
FM600-Q6 Series Pneumatic Thin Type Ball Valves



FM600-Q6 Series Pneumatic Thin Type Ball Valves

PNEUMATIC OVERALL MEASUREMENT CHART-PN 16(16bar)

DN Outline Measurement Connection Dimension Actuator Model
d L L1 L2 H1 H2 D D1 D2 N-M
15 14 36 159/172 73/85 48 73/90 88 65 45 4-12 FMATD52/FMATE63
20 19 40 159/172 73/85 53 73/90 98 75 58 4-12 FMATD63/FMATE75
25 24 44 172/185 85/95 59 90/100 105 85 68 4-12 FMATD63/FMATE83
32 29 52 185/215 95/105 71 100/110 130 100 78 4-16 FMATD75/FMATE92
40 38 64 215/265 105/110 76 110/120 148 110 88 4-16 FMATD83/FMATE105
50 48 83 215/270 105/125 85 110/142 165 125 102 4-16 FMATD83/FMATE105
65 63.5 107 270/310 125/142 102
142/158
185 145 122 4-16 FMATD105/FMATE125
80 76 120 270/310 125/142 112 142/158 200 160 138 8-16 FMATD105/FMATE125
100 95 145 310/400 142/160 146 158/178 217 180 158 8-16 FMATD125/FMATE160

According to different torques, different air source pressures and different actual working conditions, select the corresponding actuator and its relevant external dimensions also change.

FM600-Q6 Series Pneumatic Thin Type Ball Valves

Model Description

M odel Denotation Mode

FM Company Brand

-600 Pneumatic

-Q6 Thin Type Ball Valve

-C7 Butt Clamp

-F PTFE

-16 Nominal Pressure

-P Stainless 304

-80 Nominal Diameter

-E1 Single Acting Close

-B Exd Ⅱ BT4

-W2 -20~150℃

-B3 2 Bits 3 Way Anti-explosion Solenoid Valve

-B7 Anti Explosion Limit Switch



FM600-Q6 Series Pneumatic Thin Type Ball Valves


Product Usage

  FM600-Q6 pneumatic thin ball valve is a kind of pneumatic ball valve. It is a new generation of ultra-short flange distance ball valve developed by introducing Italian technology for domestic design. The shape of the ball core channel is rectangular, V-shaped and O-shaped. The product has the characteristics of compact structure, small volume, light weight and convenient installation, etc. It can be widely used in petroleum, chemical, metallurgy, power station, light industry and other fields to automatically adjust or adjust oil, water, gas and pulp or fibrous fluids cut off control.
