Jinma, JM
| Tractor Parameters | Model | JM-254 | JM-280 | JM-250 | JM-244E | JM-284 | |
| Drive Type | 4WD | 2WD | 2WD | 4WD | 4WD | ||
| Overall Dimensions L*W*H(mm): | 3080x1440x1930 | 3080x1280x1930 | 3080x1280x1930 | 3185x1440x2530 | 3080x1440x1930 | ||
| Wheel Track (mm) | Front | 1100 | 970-1270 | 1070-1270 | 1100 | 1100 | |
| Rear | 1040-1200 | 1040-1200 | 1040-1200 | 1040-1200 | 1040-1200 | ||
| Wheel Base(mm) | 1645 | 1595 | 1595 | 1645 | 1645 | ||
| Ground Clearance (mm) | 295 | 340 | 340 | 295 | 295 | ||
| Rated Traction Force(N) | 5980 | 5200 | 5200 | 5980 | 5980 | ||
| Construction Mass(kg) | 1140 | 1040 | 1040 | 1380 | 1140 | ||
| Min.Turning Radius(m) | 2.8 | 2.75 | 2.75 | 2.8 | 2.8 | ||
| Theoretical Speed (With out creeper gear(km/h) | Forward | 1.73,3.42,5.71,8.01,15.80,26.40 | 2.1,4.15,6.93,9.72,19.2,32 | 2.06,4.07,6.79,9.52,18.8,31.4 0.38,0.76,1.27,1.78,3.51,5.85 | 1.73,3.42,5.71,8.01,15.80,26.40 | 1.73,3.42,5.71,8.01,15.80,26.40 | |
| Reverse | 1.37,6.35 | 1.67,7.71 | 1.63,7.55 0.30,1.41 0.31,1.44 | 1.37,6.35 | 1.37,6.35 | ||
| Theoretical Speed (With creeper gear(km/h) | Forward | 0.32,0.64,1.06,1.49,2.95,4.92 | 039,0.77,1.29,1.81,3.58,5.97 | | | | |
| Reverse | 0.26,1.18 | 0.31,1.44 | | | | ||
| Engine Specifications | Model | Y385/KM385 | Y385T | 385 | KM385TE | 385 | |
| Type | 3-Cylinder Vertical,water cooled,4 stroke cycle | 3-Cylinder Vertical,water cooled,4 stroke cycle | 3-Cylinder Vertical,water cooled,4 stroke cycle | 3-Cylinder Vertical,water cooled,4 stroke cycle | 3-Cylinder Vertical,water cooled,4 stroke cycle | ||
| Rated Power(kw/hp) | 18.4/25 | 20.5/28 | 18.4/25 | 17.6/24 | 20.5/28 | ||
| Rated Speed (rpm) | 2350 | 2400 | 2350 | 2350 | 2400 | ||
| Bore*Stroke(mm) | 85*90 | 85*90 | 85*90 | 85*90 | 85*90 | ||
| Total Displacement(L) | 1.532 | 1.532 | 1.532 | 1.532 | 1.532 | ||
| Drive System | Clutch | Dual-Stage | Dual-Stage | Dual-Stage | Dual-Stage | Dual-Stage | |
| Gear Box | (3+1)*2 | (3+1)*2 | (3+1)*2 | (3+1)*2 | (3+1)*2 | ||
| Main Drive | One Pair of Spiral Bevel Gearing | One Pair of Spiral Bevel Gearing | One Pair of Spiral Bevel Gearing | One Pair of Spiral Bevel Gearing | One Pair of Spiral Bevel Gearing | ||
| Differential | Bevel Gear | Bevel Gear | Bevel Gear | Bevel Gear | Bevel Gear | ||
| Differential Lock | Jaw Lock | Jaw Lock | Jaw Lock | Jaw Lock | Jaw Lock | ||
| Final Transmission | External gearing, Spur Gear | External gearing, Spur Gear | External gearing, Spur Gear | External gearing, Spur Gear | External gearing, Spur Gear | ||
| Traveling Mechanism | Tyre | Front | 6.00-16 | 5.00-15/4.00-16 | 5.00-15/4.00-16 | 6.00-16 | 6.00-16 |
| Rear | 9.5-24 | 9.5-24 | 9.5-24 | 9.5-24 | 9.5-24 | ||
| Steering Gear | Full Hydraulic Steering | Full Hydraulic Steering | Full Hydraulic Steering | Full Hydraulic Steering | Full Hydraulic Steering | ||
| Brake | Disc type | Disc type | Disc type | Disc type | Disc type | ||
| Working Device | Hydraulic System | Lifting Capacity at 610mm Behind Lift Point (KN) | 4200 | 4200 | 4200 | 4200 | 4200 |
| 3-Point Suspension | Category:I | Category:I | Category:I | Category:I | Category:I | ||
| P.T.O Shaft | Rotating Speed (rpm) | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | |
| Spline Size | 6-Φ35Rectangular Spline | 6-Φ35Rectangular Spline | 6-Φ35Rectangular Spline | 6-Φ35Rectangular Spline | 6-Φ35Rectangular Spline | ||
| OPTIONS | ROL BAR,CANOPY,SHUTTLE,HYDRAULIC STEERING,TURF TYRE,CAB | ROLL BAR,CANOPY,SHUTTLE,HYDRAULIC STEERING,DUAL STAGE CLUTCH,TURE TYRE,CAB | ROLL BAR,CANOPY,SHUTTLE,HYDRAULIC STEERING,DUAL STAGE CLUTCH,TURE TYRE,CAB | ROLL BAR,CANOPY | ROLL BAR,CANOPY,SHUTTLE,HYDRAULIC STEERING,TURF TYRE,CAB | ||
