S6 Screw Type Multifunctional Mortar Spraying Machine

It adopts imported Debaoso 2L6 screw and rubber sleeve and is equipped with integrated control box and integrated multifunctional mixer, which can be directly fed.

Quantity:



Inquire Add to Basket

Model:
S6
Brand:
FOTMA
Model:
S6
Driving power:
7500W
Delivery flow:
50L/min

Product Description

S6 Screw Type Multifunctional Mortar Spraying Machine

(fireproof mortar / dry mixed ready-mixed mortar / external thermal insulation mortar)

Introduction:
Adopt imported Debaoso 2L6 screw and rubber sleeve.
Equipped with integrated control box and integrated multifunctional mixer, which can be directly fed.

Scope of application:
It is suitable for site mixing mortar, painting / light painting mortar, reinforcement mortar, cement interface, clay, renovated mortar, masonry mortar / lightweight mortar, insulation mortar, crack resistant mortar, putty, building glue, adhesive, fire proof mortar, epoxy coating, repair mortar, floor mortar, adhesive mortar, tile and filling mortar, bottom coating, cement base ash, lime mortar, relief and modeling mortar,antiseptic chalk material, etc.

Product features:
  Mature technology, large flow, stable performance, doubled efficiency, simple operation.

Work advantages:
  ●The 56 delivery pump has a large delivery volume and a long delivery distance. It can reach a horizontal distance of 100 meters and a vertical height of 50 meters.
   ●Equipped with a one-piece control box.
   ●One-piece multifunctional mixer for direct feeding.
   ●There is an oil seal between the gear motor and the hopper.
   ●Tighten design.
   ●Easy to maintain and clean.
   ●One-piece support, easy to carry.
   ●Inclination hopper, the material automatically flows to the pump port.
   ●The mixer has a replaceable inner village.

          S6 Screw Type Multifunctional Mortar Spraying Machine

TECH DATA
Specification model	S6 Mortar Spraying Machine
Voltage	380V
Driving power	7500W
Stirring drive	2200W
Delivery flow	50L/min
Delivery pressure	40bar
Conveying distance	100m
Conveying height	50m
Maximum particle size	8mm
Pumping hopper capacity	150L
Mixer hopper capacity	170L
Feeding method	Blender mixing
Total Weight	278kg
Package dimensions	19390 138cm
