XM35-200E Cold Milling Machine

XM Series pavement milling machine is one of the main asphalt concrete road maintenance equipment, mainly used for large-scale highways, urban roads, airports, freight yard, etc for renovation of asphalt pavement. One-time removal of entire concrete overlay. It can also be used for cleaning protuberance, oil layers, retieulation and vehicle tracks as well as road trench, tunnel excavation. cement road surface roughening and dislocation smothness.
The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation.
Performance and characteristic
⊙High strength milling rotor drive by belt ,reliable and high efficiency.
⊙Four tracks driving system ,power traction ,four kids of steering modes ,flexible to travel.
⊙Full automatic power adjusting system ,realizing the automatic power distribution between the milling power and driving power.
⊙Advanced automatic control system of milling depth ,easy operation and reliable.
⊙Electrical control engine Nation Ⅲ emission standard ,reliable and economical efficiency of fuel comsuption.
⊙All hydraulic components and transmission parts adopts international well-known brands ,advanced performance and reliable operation.
XM35 XM50E XM100 XM200E

Max. milling width mm 350 500/350 1020 2000

Max. milling depth mm 60 100 120 300
Milling wheel Number of tools
38 44 84 162
Drum diameter with tools mm 460 580 660 980
Engine Model
YC4D80-T11 YC4D95Z-T21 YC6108ZG DHP12
Rated power kW 56 70 115/154 353
Rated speed rpm 2200 2200 2200 2100
Specifications Operating speed m/min 0~25 0~38 0~13 0~34
Travel speed km/h 0~6 0~6 0~13 0~5
Ground clearance % 20 50 >20 80
Ground clearance mm <80 <100 120 <320
Min. turning radium  m

Operating weight kg 4350 4800 13000 28500
Volume Fuel tank L 90 90 180 800
Hydraulic oil tank L 70 70 150 300
Water tank L 220 220 350 2300
Conveyor Width mm

Measurement Overall machinery LxWxH mm 2820*1225*2050 2880*1435*2050 4522*2218*2804 6750*2500*2900
Conveyor LxWxH mm

Travel mode
Tire Tire Tire Track
